Pinebark Ranch House Plan | Single Story Home | Blueprint PDF (Slab on Grade Foundation)
ITEM DETAILS
- 3 Bedrooms
- 2 Bathrooms
- Width: 50 ft.
- Length: 28.5 ft.
- Heated Area: 1,425 sq. ft.
This is the Slab On Grade version of The Pinebark.
Spacious, affordable, and thoughtfully designed for everyday living.
The Pinebark is a single-story, 3-bedroom, 2-bath rancher-style home plan designed for first-time homeowners, growing families, or anyone seeking a simplified lifestyle with modern comfort. With 1,425 square feet of heated living space and two covered porches, this home combines functionality and charm.
The layout features a large open living area, an island kitchen with bar seating for three, and a dedicated laundry room with side entry. The primary bedroom has its own private bath, while two additional bedrooms share a full hallway bath—making this design perfect for small families, in-laws, or long-term guests.
Constructed with a slab on grade foundation and 2×6 framing, The Pinebark is both energy-efficient and builder-friendly.
🔹 Looking for more 3-bedroom home plans? Favorite our shop to stay updated with new designs!
This complete set of architectural plans includes everything you need to build, featuring detailed construction drawings, and a materials list.
Plan Features:
✅ Size: 50’ x 28’6”
✅ Total Heated Area: 1,425 sq. ft.
✅ Porches: Covered Front & Rear (20’ x 6’ each)
✅ Bedrooms: 3
✅ Bathrooms: 2 Full Baths
✅ Ceiling Height: 8′ 1 1/8″
✅ Foundation: poured concrete walls with insulated concrete slab floor
✅ Framing: 2×6 Exterior Walls
✅ Roof Framing: Stick Framed
✅ Overall Height: Approx. 18’8”
What’s Included in Your Purchase:
📐 Complete Architectural Floor Plans (PDF) – Professionally drawn and labeled
🛠 Material Estimate List – Helps simplify budgeting and ordering
🏡 Functional Layout – Open concept living, private primary suite, and dual porch access
💡 Code-Conscious Design – Compatible with most North American building standards
📩 Need modifications? Send us a message to discuss custom plan options.
This is a DIGITAL DOWNLOAD. No physical item will be shipped. Files are formatted to print on 11″x17″ sheets for easy use.
Why Choose MC Creative Blueprints?
✔ Professionally designed with 25 years of experience
✔ Easy-to-follow construction plans, optimized for builders & DIYers
✔ Instant download so you can start planning today!
⚠ Copyright Notice: These plans are for personal use only. Redistribution or commercial use is prohibited.
🔨 Ready to build your ideal starter home? Download The Pinebark plan and get started today!
